Description and Specification for Lab Tenders
Monocular Research Microscope, Coaxial Focussing 45°.
| Body: | 45-degrees inclined monocular head rotatable through 360 degrees. Quadruple nose piece with accurate centering and positive click stops, revolves on high grade steel balls & dust proof carrier to ensure smooth rotation & maintain parfocality. |
| Stage: | Mechanical stage of 120x140mm. Low co-axial drive controls for X-Y movement with fully graduated vernier scale for manipulation of specimen slide. |
| Focussing: | Co-axial coarse and fine focussing for easy manipulation based on four stage reduction gear system & travelling on ball bearing guide ways with virtually no wear, tear and free from backlash. Tension adjustment ring on one side. |
| Illumination: | 6V-20W halogen lamp or 3W LED white light illumination, operating on 220/110 Volts. |
| Condenser: | Two lens Abbe condenser N.A. 1.25 with filter support, movable by rack & pinion arrangement. |
| Eyepiece: | Wide Field 10X and either of Huygenian 5X or 15X. |
| Objective: | Achromatic DIN Standard 45mm 4X, 10X, 40X SL and 100X SL oil immersion. |
| Box: | Supplied in a plywood box with essential accessories namely eye guard, filters, immersion oil, vinyl cover, cleaning paper, cleaning brush, dust blower. |
