Description and Specification for Lab Tenders
Trinocular Research Microscope, Basic.
| Body: | 45 degrees inclined trinocular head rotatable through 360 degrees. Quadruple nose piece with accurate centering and positive click stops. |
| Stage: | Mechanical stage of 120x140mm. X-Y movement with fully graduated vernier scale for manipulation of specimen slide. |
| Focussing: | Separate fine and coarse focussing using diagonally cut rack and pinion arrangement. |
| Illumination: | 6V-20W halogen lamp, operating on 220/110 Volts. |
| Condenser: | Two lens Abbe condenser N.A. 1.25 with filter support, movable by rack & pinion arrangement. |
| Eyepiece: | Two paired eyepiece sets, one is Wide Field 10X and the other is either Huygenian 5X or 15X. |
| Objective: | Achromatic JIS Standard 36mm 4X, 10X, 40X SL and 100X SL oil immersion. |
| Box: | Supplied in a plywood box with essential accessories namely eye guard, filters, immersion oil, vinyl cover, cleaning paper, cleaning brush, dust blower. |
