Winch
Technical Description:
The allows to study a winch concerning its lifting velocity and its load transmission. Additionally, the functioning of a back-run safety device is demonstrated. Load transmission and efficiency can be determined by force equilibrium. Both rope drums are ball-bearing mounted. The forces are generated by sets of weights and can be quickly and easily varied.
Specification:
1. Study of a winch 2. Drum and driving wheel made of aluminium, gear wheels made of POM 3. 2 sets of weights 4. Safety catch prevents reversal of direction of rotation 5. Anodised aluminium base plateTechnical Data:
Drum diameters
- driving: 220mm
- driven: 110mm
Gear wheels
- small: 12 teeth
- large: 60 teeth - module: 2mm each
Total transmission ratio: 10
Sets of weights
- drum: 1x50N, 2x20N, 1x10N
- driving wheel: 1x5N, 4x2N, 1x1N, 1x0,5N, 1x0,5N (guide rod)
