Inverted Microscope
Microscope

Inverted Microscope

Inverted Microscope: infinity Optical System; siedentopf Trinocular Head inclined at 30°, Interpupillary 48 - 75 mm; high - Point, Extra Wide Field Eyepiece…

Price
On request, by quantity and destination
Tender documents
Specification sheet and quotation on request
Category
Microscope

Product details


Specifications:

  • Infinity Optical System
  • Siedentopf Trinocular Head inclined at 30°, Interpupillary 48 - 75 mm
  • High - Point, Extra Wide Field Eyepiece EW10X/22
  • LWD Infinitive PLAN objectives : 4x/0.1 WD18mm, 40x/0.6 WD 2.6mm (Cover Glass 1.2mm)
  • Infinitive PLAN PHASE objectives : PH 10x/0.25 WD10mm, PH 20x/0.4 WD 5.1 mm
  • Quintuple Nose Piece
  • ELWD Condenser NA0.3, LWD72mm, (Without Condenser 150mm)
  • 10X - 20X, 40X Phase Annulus Plate
  • Plain Stage 160x250mm, Glass Insert, Auxiliary Stage 70 x 180 mm
  • Coaxial Coarse & Fine Adjustment, Vertical Objective Movement. Coarse Stroke 37.7 mm per Rotation and Fine Stroke 0.2 mm per Rotation
  • Illumination : Halogen Lamp 6V/30W
  • Filter diameter 45 mm, Blue, Green & Ground Glass
  • Power supply (110V/220V)
  • Dust Cover
